Description

2014 Multivac T800 Automatic Tray Sealer in good operational condition.
Machine frame made of stainless steel
Max. possible tray depth 130 mm
Servo actuated lifting system
Automatic die locking system. Allows fast and easy die change without tools and automatic connection ofall die utilities without cables, hose connections, etc.
Gripper system for exchangeable tray grippers
Operation of machine is possible from either side. Machine direction is from right to left.
SAFETY
Interlocked side frame claddings at lifting systems (with magnetic switches)
Set of protective lids made of stainless perforated plate
FILM UNWINDS
Film unwind FA 80, 3″ core−ø; mechanic clamping of the film reel with parameter-driven low web indicator and end of web detector
Film advance for precise positioning and perfect film transportation
Film buffer system via reserve loop, system provides for a constant film tension during the film advance
Residual film rewind for controlled rewind of the film rest grid
PRINT REGISTRATION
Photoelectric print registration, type DMS 80, for top web, for processing of register−printed films
PNEUMATIC EQUIPMENT
Electrical: 220 volts, 3 phase, 60 hertz
